Soudafix VE400-SF Styrene Free Vinylester 2-Part Resin 280ml

** REDUCED TO CLEAR **

Fire Resistance class F120 (M8-M30)

Watertight and impermeable fixing

Overhead installation allowed

OUT OF STOCK - PLEASE ALLOW 1 WEEK PLUS DELIVERY SERVICE

FREE STANDARD DELIVERY ON ORDERS OVER £100*

FREE STANDARD DELIVERY OVER £100*

Soudafix VE400-SF is a high-performance two-part vinylester chemical anchor, suitable for use in a wide range of building materials. Soudafix VE400-SF is ideal for anchoring threaded rods in masonry (18 brick types) and uncracked concrete (ETA approval option 1). Soudafix VE400-SF resin has a fire resistance class of R120 and has ETA approval for threaded rods (M8-M30) and reinforcement bars (ETA: Ø8-Ø32).

This is low-odour styrene free resin, which is suitable for use in dry, wet, and water-filled holes.

Features & Technical

Wide application area, even in wet drill holes, under water and at temp. as low as –10°C
European Technical Assessment Option 1 for non-cracked concrete
Approval for threaded rods in masonry from M8 up to M30
Can be applied with standard caulking gun
Fire Resistance class F120 (M8-M30)
Dry, wet, and water-filled drill holes
Watertight and impermeable fixing
Indoor air emission class A+
Styrene free (low odour)
C1 Seismic resistance
Overhead application
Fast curing
Technical data sheet

Specifics

Base: Vinylester styrene free
Cartridge size: 280ml
Temperature resistance: -40 °C to + 120°C
Application temperature: -10°C to +40°C
Elasticity modulus: 14000 N/mm²
Maximum bending tensile strength: 15 N/mm²
Maximum compression strength: 100 N/mm²
Approx no. of M8 fixings per tube at embedment depth of 80mm: 61
Approx no. of M10 fixings per tube at embedment depth of 90mm: 38
Approx no. of M12 fixings per tube at embedment depth of 110mm: 23
Approx no. of M16 fixings per tube at embedment depth of 125mm: 12
Approx no. of M20 fixings per tube at embedment depth of 170mm: 5
Approx no. of M24 fixings per tube at embedment depth of 210mm: 3

Technical Data Sheet
